Description
- Output torque
T2N : 12 Nm – 3,200 Nm - Ratios
1-stage : 1/1.5/2/3/4/5 - Low backlash
1-stage : ≤6arcmin - high efficiency
1-stage : ≧ 98% - Easy mount
- Low Noise
- Compact structure
$50.00
The Apex AT-H series is a right angle spiral bevel gearbox with hollow keyed output and input shaft configuration. High radial load capacity and high precision make the AT-H series suitable for servo applications as well as power transmission solutions.
NEW! – Now available in Carbon Steel as ATB version!
